280W 3in1 beam pattern moving head light is a multi-functional lamp, which is a stage dedicated lamp with a special 3D vertical effect. A multi-functional lamp. The new optical design is linearly zoomed and the pattern spot is very uniform. It is based on the beam effect, which enhances the beam function. Through a well-designed optical system, the beam is smoother, tighter, and has even brightness and impact. Also take into account the Spot、Wash function. All kinds of effects are superior to the same type of products, especially in the clear imaging of brightness, light beam opening angle, color temperature, pattern beam. Increased brightness and enhanced pattern features in previous products in the market. Whether it is used in a rental show or a bar project is the best choice for beam lights.
Voltage : 110 V~240 V/50-60 Hz
 Lamp : Osram 280W
Average power: 470W
Ballast: Electronic Ballast
Source life: 2200Hrs
Channel: 24 channels
Lens : high precision optical lens
Pattern angle: 5°-20°
Light speed angle: 2.5°-10°
Beam angle: Electric focus, 3.8-45°
Control mode : Standard DMX512, Auto,Master/ slave mode
Channel : 16 CHs / 24 CHs
Color wheel: 13 plug-color film + white
Static Gobo wheel with 14 fixed gobos, at variable rotation
Rotating Gobo: 9 bidirectional and indexable gobos
(outside diameter: 15,4 mm, image diameter: 13 mm)
Static Gobo : 14 fixed gobos, at variable rotation
Prisms: Rotate 6-sided linear prisms and 8-sided ring
prisms, bidirectional rotation, adjustable speed.
Atomization: soft light effect, easy soft and dreamy pattern effect
Focusing: linear autofocus, can project high-definition patterns
Strobe: 15 times/sec, adjustable speed
The X-axis rotates 540° horizontally and the Y-axis moves
270° vertically. Automatic correction positioning
Display: LED touch screen + 4 key screens.
3-pin XLR signal plug, output input power audio plug
Built-in multiple self-propelled programs, automatic ，calibration analysis program
Net Weight : 19kG
Dimension: 38.6 (L) X 36.5 (W) X 58.9 (H) cm
Package:45x43x57cm
Features:
1, beam, pattern, dyeing, zoom four in one, the pattern can be automatically enlarged.
2, light bulb: 280W full power light bulb, optical lens: 3 sets of optical lens combination.
3, color: with 13 colors + white, rainbow effect, half-color effect.
|
