440W 20R Moving Head Beam Light is an advanced hybrid light, it is an very powerful beam light, the light beam is sharp and the minimum beam angle is just 2.5°. The narrow and dense light beam remains parallel even at very long distance.
It is also a professional high power spotlight with a zoom from 4°to 50°, rotating gobos and fixed gobos, CMY color mixing, three color wheels, animation wheel, double prisms, “Auto focusing “ function, and smooth, fast and quiet movement. Modular design easier the repairing and maintenance.440W is a versatile fixture and can be used in any situation.
Voltage: AC110-240V, 50 / 60Hz;
Rated power: 600W;
Channel mode: 16 / 19CH;
Light source: 20R 440W
Display: 2.8 inch touch screen, canbe reversed 180 °
Color plate: 14 color film + white light;
Fixed pattern plate: 14 patterns + white light;
Prism: out of 11 kinds of prism effect，Consists of two rotating prism plates;
prism plate one: 16 prisms, one straight 6 prism, one atomized;
Prism plate two: 32 prisms, one straight line 6 prisms
double prism(6 prisms + 12 prisms)
Light angle: 4 ° or 6 °;
Dimming: 0-100% mechanical dimming, mechanical strobe and support Speed strobe effect, strobe macro support, lens
group optical system The use of optical reset system, when misoperation occurs automatically Search reset
Positioning technology: the use of magnetic positioning systemusing magnetic devices instead of the traditional Hall positioning system. Higher accuracy, high performance and reliability.
Level: 540 °, resolution 8 / 16Bit;
Vertical: 270 °, resolution 8 / 16Bit;
IP protection class: IP20
EFFECTS
Animation disc
2 indexable and interchangeable rotating prisms
Zooming and Auto-focusing at prism
Independent frost filter
Adjustable speed strobe effect
|
