The 440 waterproof lamp uses CFD software to analyze and calculate the heat flux of the lamp, designing a low-noise cooling system, excellent fan driving performance, and extremely low noise. The high temperature resistant atomizing sheet can make this lamp have a dyeing effect. The body is made of die-cast aluminum design material, and the cooling speed is very fast. The built-in dehumidification and heat dissipation patented technology device has a waterproof and dustproof function. Horizontal and vertical use of custom three-phase motors, lamps can do 540 ° horizontal or 270 ° vertical scan, fast and smooth, more horizontal and vertical locking buttons, more convenient maintenance and handling, and the lamp set intelligent photoelectric reset correction system, In case of accidental misoperation, it can automatically return to its original position. Applicable to outdoor performance rental, project lighting, resorts, bridges, fountains, theme parks, rooftops and other places.
Input voltage: AC 90-240 V ，50-60 Hz
Light source power: 440W
Machine power: 600 W
Light source theoretical life of more than 1500 hours
Lamp color temperature: 7800K / 7500K
Focusing: Linear electric focusing
Color temperature : 2500K/3200K
Dimming: dimming smoothing without flicker
Light Source: Osram 440W
Ballast: Osram S20
Strobe: independent strobe, 0.5-20 times / sec adjustable
Color / pattern / effect
Color plate: 11 color pieces (customizable CMY)
Beam angle: 2 °
Lens diameter: 170 mm
Dot bubble function: remote DMX controller control point bubble, bubble, at the same time can display panel settings open light bulb function
Beam: beam size can be adjusted
Display: High-end touch LCD LCD display, LCD display adapts to different mounting positions
Fixed pattern disk 12 + 1 + can be two-way jitter, animation, water effect
Prism ：16 Prism Mirror (Standard, Customizable)
Control: DMX 512, voice, Auto, master and slave
Rotation angle: X axis 540 degrees, Y axis 275 degrees can automatically ，correct the positioning
Channel :Standard 16-channel with CMY 20 channels
Lamp material: the use of high-strength PA66 with high temperature, anti-aging wear, light drop and other characteristics
Protection class: IP 65
Lamp body size: 418 * 378 * 620 (mm) 25kg
Carton Size: 440 * 420 * 810mm 27kg
|
